Nickel Plating

Nickel symbol_page-0001

Nickel plating provides a unique combination of corrosion and wear resistance. It can add brightness, lustre and appeal. It also provides excellent adhesion properties for subsequentcoating layers, which is why nickel is often used as an ‘undercoat’ for other coatings, such as chromium.

Typical specifications for nickel plating services include QQ-N-290 and ASTM B689.



There are three standard types of nickel plating, each of which is useful for particular applications:

  • Bright Nickel Plating – provides a smooth, level, and very glossy finish typically valued for its decorative appearance and corrosion resistance.
  • Semi-Bright Nickel Plating – provides a less bright finish with high ductility, corrosion-resistance, and electrical conductivity, making it ideal for engineering and building applications.
  • Dull nickel plating – dull nickel plating is the least bright finish, with high resistance to abrasion, corrosion, and wear, making it perfect for engineering applications.

Nickel Plating Specifications

QQ-N-290

Classes
1. Corrosion protective plating
2. Engineering plating
Thickness Grades
0.0016 inch
0.0012 inch
0.0010 inch
0.0008 inch
0.0006 inch
0.0004 inch
0.0002 inch

ASTM B689

Class
5. 5 um (.0002”) Thickness
25. 25 um (.0008”) Thickness
50. 50 um (.002”) Thickness
100. 100 um (.0039”) Thickness
200. 200 um (.0078”) Thickness
X. Thickness as specified
